Nic Piraino

Electrical Engineering, UBC Okanagan

Focus
  • Precision analog
  • PCB design
  • Embedded systems
Program
BASc Electrical Engineering + Master of Management

StatusSeeking a hardware / PCB design internship, winter or summer 2027

Photographs
Northern Lights
Northern Lights
  1. The revised motor: printed PETG HF base and rotor, steel-bolt stator teeth and hand-wound copper coils

    Three-phase BLDC inrunner

    ENGR 320 · Jan – Apr 2026

    Role
    Research & Presentation Lead, five-person engineering team
    Decision
    Near-zero torque turned out to be two faults: PLA stator teeth with a relative permeability of about 1, and a winding that cancelled itself. Steel-bolt teeth (with four times the turns) and a regrouped winding fixed both.
    Result
    Spins up cleanly on the revised winding. (Observed, not measured) $94.92 of a $100 budget. Speed, torque and efficiency are not reported.
  2. An HP 3458A multimeter reading 9.9999927 volts DC at the reference output

    LTZ1000 10 V reference

    Measurements International · May – Aug 2026

    Role
    Hardware engineering intern: laid out and assembled two boards to a senior engineer’s design direction
    Decision
    The design moved from an ADR1000 to an LTZ1000, which does not sit at the same voltage, so the 10 V gain network was recalculated from what the new reference actually produced.
    Result
    An HP 3458A read 9.9999927 V at the 10 V output during pre-calibration testing. (Measured) A development reading, not a calibrated specification.

    Hardware and data remain the property of Measurements International Ltd.

  3. Okanagan Rover Craft’s rover on rough ground at CIRC 2026: copper-clad electronics box, antenna mast, arm and four yellow printed wheels

    Rover power system

    Okanagan Rover Craft · CIRC · Sep 2025 – present

    Role
    Electrical engineer
    Decision
    An XT90 rated about 40–45 A sat on a 50 A-class battery path, and CIRC sizes each circuit’s protection to its smallest connector. That fed the revised requirements: one 25.6 V LiFePO4 pack with per-cell undervoltage lockout, protected at the battery and feeding individually fused branches and DC-DC converters.
    Result
    Ongoing. Battery selected in October 2026; not yet installed or tested. Team result: 14th of 27 at CIRC 2026, before this battery was chosen.

About

I build hardware that has to answer to an instrument: precision analog, PCB design, embedded systems and electrical metrology.

A schematic predicts what a circuit should do and a simulation models it. The part I care about starts once the board exists and has to prove it. A three-phase motor wound by hand, which needed rewinding before it would spin up. A waste classifier pointed at real rubbish instead of a tidy sample set. A 10 V reference whose entire job is to sit still.

Where a number here was calculated rather than measured, the write-up says so. Those are not the same thing, and blurring them is the easiest way to make work look better than it was.
